1 Piece/Batch 380v Automatic Electric Drill Drilling Machine 1000DX Milling Machine 180w Low Noise Power Feed/Drill Machine

<p>Switch direction without noise, and very labor-saving, easy control.</p><p>When fast escort, if the tool collision parts, or about instantly reversed, with safety devices, plastic gear transmission and electronic componentswould not get damaged.</p><p>Quick escort button set on the switch direction handle,can operation quickly when working, with inching function in any feed rate, can easily reach the workpiece machining position</p><p>Limit switches with patented, waterproof, anti-oil, dust protection cover, switch noteasily getdamaged</p><p>Gearof screw drive usespiral bevel gear, high efficiency, low noise</p>

• Electric Drill Drilling, Milling Machine, Machinery & Accessories, Tools
• Features:
• - Speed adjustment efficiency is good, when the tool doing cutting work, escorting changing speed is small, accuracy is good and smooth cutting surface, low-speed escort, the machine will not shake
• - Plastic gear for driving with spindle motor gear ratio is infinite decimals,will not return original point when running,plastic gears arelonger life, the more you use,the smallernoise of gears.
• Advantage:
• 1. Mechanical structure with strong torque.
• Breaking through the structure of the traditional POWER TABLE FEET, it adopts mechanical gear transmission, which has strong torque and can withstand fast feed and high feed speed.
• 2. Strong transmission.
• It is driven by a 1/2HP motor and the load is due to the traditional POWER TABLE FEET.
• 3. Electrical protection.
• It is equipped with an electric control box to protect the motor from damage due to overload and ensure the life of the motor.
• 4. Easy to install.
• The user can install it on the milling machine without special techniques and without affecting the precision of the machine.
• 5. Overload safety trip device.
• The gearbox has an overload safety clutch to protect the gears inside the gearbox and has a long service life.
• 6, low noise, strong lubrication.
• The gear box is oil-immersed, the gear transmission is smooth, the noise is small, and the lubrication is strong.
• 7, 5 kinds of feed speed, suitable for a variety of processing conditions.
• Feeding 25MM, 60MM, 115MM, 210MM, 800MM per minute, can provide a variety of processing conditions; another rapid advance and retreat 800MM / min, can save the gap time of the knife, so that the workbench quickly run to the starting point of processing.
• 8, the action is light, does not hinder the work schedule.
• The gear box is small in size, does not hinder the working stroke, and can be manually fed to directly drive the lead screw of the milling machine, without the gear transmission in the gear box, and the hand feels light.
• product properties:
• Model: 1000DX
• Control method: vertical
• Suitable: milling machine X-axis, install the standard aperture of 16MM, if your milling machine screw is not 16MM, please process it.
• Motor: 180W, 50Hz
• Motor input voltage: 380V
• Speed range (r/min): 3,12,23,42,160
• Torque range: 5.6-225N.M
• Net weight: 12KG
• Gross weight: 13KG
• Noise: less than or equal to 50 decibels
